vertical type graphitization furnace

type：induction furnace

processed materials：380v±10%，50hz/60hz 3 phase 5 wire,one control cabinet to one furnace and optional for one to two type or one to four type.

applications：the equipment mainly used in the ht heating treatment on carbon material, carbon nano, carbon fiber, negative electrode materials, graphite powder, contacting terminal material and such related material.

leave message
  • overview
  • specifications
  • features

 graphitizing furnace is applicable in high temperature graphitization treatment of thermal conductive material graphite film,new materials, carbon and carbon materials, special ceramics industry.

照片 570

[s]照片 002

       model               parameter

lab usage

production usage

nti-sml-4l

nti-sml-9l

nti-sml-57l

nti-sml-100l

nti-sml-206l

nti-sml-339l

nti-sml-602l

ntg-sml-1177l

working size
（d×h）

mm

φ150×250

φ200×300

φ350×600

φ400×800

φ500×1050

φ600×1200

φ800×1200

φ1000×1500

heating type

/

if induction heating

control type

/

thyristor control or igbt control ( optional )

ht zone capacity

l

4

9

57

100

206

339

602

1177

loading weight

g

               ht zone capacity × density (g/cm³)×1000        remark：1l=1000cm³

ultimate vacuum

pa

20

if power

kw

80

100

150

200

250

350

600

800

max. working temperature

℃

3200

3200

3000

3000

3000

3000

3000

3000

usual working temperature

℃

3000

3000

2800

2800

2800

2800

2800

2800

temperature unifomity

℃

±10

±10

±10

±10

±10

±10

±10

±10

working environment

/

vacuum or ar, n2 atmosphere protection( micro positive pressure)

 feature:

1.the highest working temperature: 3000℃

2.double layer alumina as keeping temperature material, good the heat insulation and fire resistance effect, less heat loss and quickly heating.

3.equipping with high strength hard composite felt at the bottom of crucible, in order to ensure that the graphite crucible at high temperature level uniform force, it is 1.5 times the service life of similar products.

 4.unique design explosion-proof valve of furnace body safe and reliable.

configuration:

1.380v±10%，50hz/60hz 3 phase 5 wire

2.one control cabinet to one furnace and optional for one to two type or one to four type.



production procedure:



vertical type 2

raw material suitable for heating:

carbon material

packing mode:
