serial no. |
name |
material |
qty |
|
1 |
the hearth（including water cooling furnace door and gas charging system） |
cr25ni20 thickness 6-8mm |
1set |
|
2 |
the furnace body |
q235a |
1set |
|
3 |
collecting device |
q235a |
1set |
|
4 |
the heater |
cr20ni80 |
3 groups |
|
5 |
the thermal insulation chamber |
|
1set |
|
6 |
the draught fast cooling system |
|
1set |
|
7 |
vacuum system |
2h-30 150 roots pump |
1set |
|
8 |
the thermocouple |
“k” type |
3pcs |
|
9 |
temperature control |
fp93 |
3pcs |
|
10 |
electric element |
chint |
1set |
|
11 |
control cabinet |
mcgs touch screen |
1set |
|
12 |
plc |
delta plc |
1set |
|
13 |
control system |
including cable |
|
|
14 |
the mechanical |
including spare parts and paint. |
|
|
15 |
management service |
|
|
|
16 |
installation and debugging |
|
|
